| BRAND | Tsubaki Kabelschlepp |
| Product | S1800.300.RR.265.St-28980 |
| Description | CABLE DRAG CHAIN (TYPE: 225) |
| Internal code | ONR4853390 |
| Custom code | 84879059 |
| Technical specification | Tsubaki cable tow energy chain - product description energy chain Chain series... STEEL-LINE - S1800 Chain name... s1800.300.RR.265.ST-28980 Material... steel (galvanized) Chain length Lk... 28,980.0 mm Division t... 180.0 mm Number of elements n... 161 [pcs] Bridge width bst... 300.0 mm Inner width Bi... 280.0 mm Outer width Bk... 329.0 mm Inner height Hi... 104.0 mm Chain link height hG... 140.0 mm Radius of curvature KR... 265.0 mm Bridge variant... RR (pipe bar with integrated steel rollers) Bridge arrangement... half-bar Number of bars nst... 81 [pcs] Bridge system/ interior layout Interior layout... no divider system connection elements Variant (fixed point/driver).. FAI/MAY |
Discover the superior quality and performance of the Tsubaki Kabelschlepp S1800.300.RR.265.St-28980 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The S1800.300.RR.265.St-28980 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of S1800.300.RR.265.St-28980 :
At Onrion LLC , we offer the S1800.300.RR.265.St-28980 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the S1800.300.RR.265.St-28980 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Tsubaki Kabelschlepp products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
connector
INNENDECKEL 0555.125 Innendeckel Typ UNIFLEX 0555.125 Identity number: 0052545
Plastic chain; Number of links per chain 20; chain length 1,250.00 mm
Chain length: 1,000.00 mm Number of links per chain: 16
connection element
TUBE
Order code .................. 0665.060.125.200-1928.5 Chain length Lk ....................... 1928.5 mm N number of links ..................... 29 Internal width bi ....................... 125 mm Outside Width 152 mm Bk ...................... Radius of curvature KR ................... 200 mm Stay variant ......................... cover both sides, inside openable Number of webs nst ..................... 29 Connection fixed point / driver ....... FU / MU Inner height hi ......................... 42.0 mm Chain link height hG ................... 60.0 mm
Order code .................. 0665.060.125.200-2726.5 Chain length Lk ....................... 2726.5 mm N number of links ..................... 41 Internal width bi ....................... 125 mm Outside Width 152 mm Bk ...................... Radius of curvature KR ................... 200 mm Stay variant ......................... cover both sides, inside openable Number of webs nst ..................... 41 Connection fixed point / driver ....... FU / MU Inner height hi ......................... 42.0 mm Chain link height hG ................... 60.0 mm
Order code .................. 0665.060.125.200-4721.5 Chain length Lk ....................... 4721.5 mm N number of links ..................... 71 Internal width bi ....................... 125 mm Outside Width 152 mm Bk ...................... Radius of curvature KR ................... 200 mm Stay variant ......................... cover both sides, inside openable Number of webs nst ..................... 71 Connection fixed point / driver ....... FU / MU Inner height hi ......................... 42.0 mm Chain link height hG ................... 60.0 mm
Spring band spiral stainless
conduit 60 baklalı
clinch CONDUFLEX
DOUBLE RACE STEG M / S1250, S / SX 1252
Power cable 700 Querschnitt 3 x 0.34 Length: 100,000.00 mm
LIFE-LINE Data 700 3x0,34²
Power cable 700 Querschnitt 6 x 0.34 Length: 100,000.00 mm
INNENDECKEL 0555.125
cradle CONDUFLEX
Lower clamp CONDUFLEX
Upper clamp CONDUFLEX
Lower clamp protection CONDUFLEX
Upper clamp protection CONDUFLEX
MC1250 Bean Locking
LASCHENENDSTÜCK MC 1250 LINKS
