| BRAND | Wika |
| Product | S5412 -4-C1E-ND-C160GZ-ZZ DIAL-T-1AZ1ZZZZZ |
| Description | Bimetal thermometer, industrial series Specifications according data sheet: TM 54.01 / 01.15 for TV Twin Temp Accuracy: Cl. 1 according to EN 13190 Housing: stainless steel Stem material: Stainless steel Type: S 5412, rotatable size 100, housing and pivotally Design of connection: 4, compression fitting sliding on stem Unit: ° C Range: 0 ° C ... 100 ° C Process connection: 1/2 NPT Stem diameter: 8 mm Installation length L1: 160 mm Window: Instrument glass Housing: stainless steel Standard mark on the dial: * EN 13190 * Accuracy of the dial: * * CL.1 |
| Internal code | ONR419857 |
| Weight | 1 |
Discover the superior quality and performance of the Wika S5412 -4-C1E-ND-C160GZ-ZZ DIAL-T-1AZ1ZZZZZ with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The S5412 -4-C1E-ND-C160GZ-ZZ DIAL-T-1AZ1ZZZZZ is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of S5412 -4-C1E-ND-C160GZ-ZZ DIAL-T-1AZ1ZZZZZ :
At Onrion LLC , we offer the S5412 -4-C1E-ND-C160GZ-ZZ DIAL-T-1AZ1ZZZZZ at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the S5412 -4-C1E-ND-C160GZ-ZZ DIAL-T-1AZ1ZZZZZ ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Wika products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
66100160 TYP S-10 MESSBEREICH: 0 ... 3000 PSI
Pressure transmitter for general applications Model S-10 Specifications according data sheet: PE 81.01 Power supply: DC 10 (14) ... 30 V Wetted components: Stainless steel Housing: stainless steel Output signal: 4 ... 20 mA, 2-wire Measuring range: 0 ... 3000 psi Process connection: 1/4 NPT Accuracy: 0.5% of span Electrical connection: Angular connector DIN EN 175301-803 A, IP65 permissible fluid temperature: -30 ... + 100 ° C Power supply: 10 ... 30 V DC Occupancy electrical output: UB = 1, 2 = 0V
GAUGE,PRESSURE:-1 TO 3 BAR,100MM DIAL,1/2" MNPT,SS 1.4571 CASE,LIQUID FILLED,MODEL #233.50.100
(Digital display type DI35 Specifications according data sheet: AC 80.03 Dimensions: 96 x 48 x 148 mm Fastening: latchable screw element (mm wall thickness up to 50) Display: LED, 5 digits of -9999 ... 99999 Accuracy: depending on the input configuration Display accuracy: e.g. for standard signals +/- 0.02% of the measuring range +/- 1 Digit Special design features: Min .- / Max value memory and code-protected input lock Input: 2 inputs for standard signals (0/4 ... 20 mA, 0 ... 10 V) with the computation function (+ - x /) Alarm outputs: 2 relays (AC 230V 5A DC 30V 2A), freely programmable Power supply: AC 230 V, 50/60 Hz Transmitter supply: DC 24 V max. 50 mA Analog position signal output: 4 ... 20 mA Protection: IP54 (front), IP00 (back) Device configuration: factory settings, device is configured by the user Customs tariff number: 85312020)
with Alloy
transmitter,Input = dc 10 – 30,Output = 4 mA to 20 mA,S# 260339Y
(Stainless steel 316L)/mbar/ 2X1/2" NPT (with adaptor)/class 1.0
Stainless steel
Bourdon tube pressure gauge, stainless steel Security Design EN 837-1 Type: 233.30 Specifications according data sheet: PM 02.04 Accuracy: NG 63 Kl.1,6 NG 100/160 Kl.1,0 Measuring system: Stainless steel Case Filling: with Nominal size: 100 mm Measuring range: pressure-measuring range Display range: 0 ... 60 kg / cm2 Process connection: 1/2 NPT Connection position: bottom Window: Laminated safety glass Pointer: Pointer standard Accuracy class: 1.0 Material measuring system: measuring system 316L Filling medium Housing: Glycerine 99.7% Manometer standard: International (Europe) Manufacturers Logo: * * WIKA
“ WIKA” ELECTRONIC PRESSURE TRASNMITTERS WITH PIZORESISTIVE SENSOR
Converters S-10 1 / 2U - 1/0 BAR 4/20 MA
(Tube pressure gauge spring, stainless steel Security Design EN 837-1 Type: 233.30 Specifications according data sheet: PM 02.04 Measuring system: Stainless steel Case Filling: with Nominal size: 100 mm Measuring range: pressure-measuring range Display range: 0 ... 160 bar Process connection: 1/2 NPT Connection position: bottom Window: Laminated safety glass Pointer: Pointer standard Accuracy class: 1.0 Material measuring system: measuring system 316L Filling medium Housing: Glycerine 99.7% Manometer standard: International (Europe) Manufacturers Logo: * * WIKA)
Tube pressure gauge element, stainless steel Type Specifications according data sheet: PM 02.02 Measuring system: Stainless steel Case Filling: with Nominal size: 100 mm Display range: 0 ... 4 bar Process connection: G 1/2 B Connection position: bottom Window: Laminated safety glass Pointer: Pointer standard Accuracy class: 1.0 Material measuring system: measuring system 316L Filling medium Housing: Glycerine 99.7%
converter
9073965 DRUCKMESSUMFORMER FUR ALLGEMEINE ANWENDUNGEN TYP S-10
Specifications according data sheet: PE 81.01 Power supply: DC 10 (14) ... 30 V Wetted components: Stainless steel Housing: stainless steel Output signal: 4 ... 20 mA, 2-wire Measuring range: 0 ... 160 bar Process connection: G 1/2 B Accuracy: 0.5% of span Electrical connection: Angular connector DIN EN 175301-803 A, IP65 permissible fluid temperature: -30 ... + 100 ° C Power supply: 10 ... 30 V DC Occupancy electrical output: UB = 1, 2 = 0V
two pens in the same product
Pressure transmitter for general applications Model S-10 Specifications according data sheet: PE 81.01 Power supply: DC 10 (14) ... 30 V Wetted components: Stainless steel Housing: stainless steel Output signal: 4 ... 20 mA, 2-wire Measuring range: 0 ... 600 bar Process connection: G 1/2 B Accuracy: 0.5% of span Electrical connection: Angular connector DIN EN 175301-803 A, IP65 permissible fluid temperature: -30 ... + 100 ° C Power supply: 10 ... 30 V DC Occupancy electrical output: UB = 1, 2 = 0V Customs tariff number: 90262020
AST G1 / 2B kt 6 22 * 56 MS 2.0401.20
(910.11 VENT Z / SPNMUF G1 / 2 DIN16271 -VA FORM A VALVE FOR PRESSURE GAUGE DIN 16271 FORM A DN4 PN400 INPUT: G1 / 2B OUTPUT: G1 / 2 clamping socket JAM: M20x1,5 MATERIAL: VENTILKOERPER / STEM bleed screw 20ST CHROME NICKEL STEEL GEM. SPECIFICATION 2154709 Accessories for pressure gauge Customs tariff number: 84818079)
Shut off Valve-Order No:9091157
Manometer
Pressure Transmitter
(Pressure gauges Transformer)
Pressure Transmitter Model A-10 For general Applications Specifications according data sheet: PE 81.60Messstoffberührte components: 316LGehäuse: 316LNichtlinearität: 0.5% BFSLEinheit: barDruckart: relative measuring range: 0 ... 250 barProzessanschluss: G 1/4 A according to DIN 3852-EDichtung: NBRzulässige medium temperature: 0 ... + 80 ° CAusgangssignal: 4 ... 20 mA, 2-wire Power: 8 ... 30 V
FROST PROTECTION THERMOSTAT
A52.080-S-C1F-GD-B080VZZ-Z DIAL-T-AAZ1ZZZZZ
Bimetal thermometer, industrial version Specifications according data sheet: TM 52.01 Accuracy: Cl. 1 according to EN 13190 Housing: stainless steel Stem material: Stainless steel 1.4571 Type: A52.080, Size 80, back mount Design of connection: standard, connection established Range: 0 ° C ... 120 ° C Process connection: G 1/2 B Stem diameter: 6 mm Installation length L1: 80 mm Standard mark on the dial: * EN 13190 * Accuracy of the dial: * * CL.1
A5300 -S-C1M-GD-C160GZ-ZZ DIAL-T-1AZ2ZZZZZ
Bimetallic thermometer, Process Industry Series Specifications according data sheet: TM 53.01 Accuracy: Cl. 1 according to EN 13190 Housing: stainless steel Stem material: Stainless steel Type: A 5300, size 3 ", back mount (axial) Design of connection: standard, connection established Unit: ° C Range: 0 ° C ... 250 ° C Process connection: G 1/2 B Stem diameter: 8 mm Installation length L1: 160 mm Window: Instrument glass
Transducer,0...45 bar 4...20 mA
