BRAND | Steimel |
Product | A-SF2/8RD-VLFM / ASF2-8RD-170017R |
Internal code | ONR4642748 |
Custom code | 84136039 |
Technical specification | Gear pump unit: SF 2/8 RD - VLFM Product no.: ASF2-8RD-170017R Dimension sheet: DPA052D-080LFM-R32 Spare part list: DET052008RD-165R Suction and pressure connection: G 1/SAE 1 Case parts: EN-GJL-250 (GG-25) Pinion shafts, noise opti.: 16MnCrS5, egh., oblique angle Storage: multi-layer MD Shaft seal: radial shaft seal Elastomers: FKM Conveying medium: lubricating oil Viscosity: 50 - 5000 cSt Temperature: 10 - 60°C Flow rate: 10.9/13 l/min. Pressure: 5 bar Speed: 1450/1740 rpm Pressure relief valve Opening pressure: 8 bar Adjustment range: 2 - 20 bar Rotation direction: right Test run: yes, with HLPD 46 Coupling: BKUA040-1419-301 Pump support with base: BLF052200100LA21 three-phase motor: LDM080-04-904 (Birkenbeul) Engine data: Output 1/2:0.75/0.8 kW Speed 1/2:1500/1800 rpm Voltage/frequency 1:230/400 volts at 50 Hz Voltage/frequency 2:265/460 volts at 60 Hz Efficiency class: IE3 with additional label (without IE2) for Voltage/frequency: 220-240/380-420 V at 50/60 Hz 250-280/440-480 V at 60 Hz Protection class: IP 55 Insulation class: F Type: B 5 Aggregate paint: without Type plate: ETY924-D-E—PE02 |
Discover the superior quality and performance of the Steimel A-SF2/8RD-VLFM / ASF2-8RD-170017R with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The A-SF2/8RD-VLFM / ASF2-8RD-170017R is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of A-SF2/8RD-VLFM / ASF2-8RD-170017R :
At Onrion LLC , we offer the A-SF2/8RD-VLFM / ASF2-8RD-170017R at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the A-SF2/8RD-VLFM / ASF2-8RD-170017R ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Steimel products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
