BRAND | Steimel |
Product | SF 8/450-RD-VLFM (left) |
Description | gear pump unit |
Internal code | ONR4823086 |
Custom code | 84136039 |
Technical specification | Product no.: ASF8/450RD (062703) Dimension sheet: DPA058D-225VLFM-R23 Spare Part List: DET058450RD--150 Suction and pressure connection: SAE 5 Material design: Body parts: EN-GJL-250 (GG 25) Shafts: 16 Mn Cr S 5, hardened Gears: EN-GJS-400-15 (GGG 40), helically toothed and nitrided Shaft seal: radial shaft seal Elastomers: FKM Storage: multi-layer MD Pumped medium: lubricating oil Viscosity: 50-5000 cSt. Temperature: 10-60°C Delivery data: approx. 430 L/min Pressure: 5 bar Speed: 975 rpm Pressure relief valve: 8 bar opening pressure Adjustment range:: 2-16 bar direction of rotation: left Test run: yes, with HLPD 46 Pump carrier with foot: BLF058450262LA01 Coupling: BKUA105-2860-301 Three-phase standard motor: LDM225-06- Engine data Power P: 30.0 kW Speed n: 975 1/min Voltage U: 525 volts - triangle Frequency f: 50 Hz Efficiency class: IE3 Protection class: IP 55 Insulation class: F Design: B 5 Aggregate paint: primed Type plate: ETY924-FLEND-PE02 |
Discover the superior quality and performance of the Steimel SF 8/450-RD-VLFM (left) with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The SF 8/450-RD-VLFM (left) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of SF 8/450-RD-VLFM (left) :
At Onrion LLC , we offer the SF 8/450-RD-VLFM (left) at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the SF 8/450-RD-VLFM (left) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Steimel products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
