| BRAND | Armstrong |
| Product | SS18H11 |
| Internal code | ONR1113532 |
| Weight | 1 |
| Technical specification | ¾” FULL STAINLESS STEEL INVERTED BUCKET INPUT-OUTPUT HAND SIDE (HORIZONTAL INSTALLATION) BODY: ASTM A240 GRADE 304 (STAINLESS STEEL) INTERNAL PARTS: AISI 304 STAINLESS SIT AND STEEL VALVE: CHROME STEEL AISI D3 (ASTM A681) NPT GEAR LİFA TO FACE: 110 MM ORIFICE, 3732 "(2.5 MM) Delta p: 17 BAR (250 PSI) MAX. OPERATING TEMPERATURE: 454 ° C MAX.WORKING PRESSURE: 28 BAR (400 PSI) DISCHARGE CAPACITY: 340 KG / H @ delta p: 17 BAR (750 LBS / N) |
Discover the superior quality and performance of the Armstrong SS18H11 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The SS18H11 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of SS18H11 :
At Onrion LLC , we offer the SS18H11 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the SS18H11 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Armstrong products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Steam Trap
08802005 880 R-3/4" VENTIL-#38
Bell condensate trap for horizontal installationwith integrated strainer with tubular socket thread BSPTMaterials፦ Housing: cast iron ASTM A48 30- Internal parts: Stainless steel 304- Valve + Seat: Stainless steel 17-4PH- Lid plugs: Stainless steel - Mudflaps: Stainless steel with cleaning wideMax. permissil. Differential pressure: 10.5 barPMo: 10.5 bar @ 232°cCustoms Tariff No: 8481 8099Country of origin: BelgiumWeight: 2.5 kg/h
VENTIL
Armstrong inverted bucket steam trap 13.5 bar,Type: 1011 Diameter: 1/2 inch Differential pressure: 13.5 bar Discharge capacity: ~ 380kg / h Orifice diameter: 7/64 inch Max. working pressure: 27 bar Max working temperature: 427 ° C Connection type: Welding socket, vertical mounting Body Material: ASTM-A 240İtip 304L/304 Internal parts: AISI 304 stainless steel Valve and sites: 440 ° F hardened chrome steel
Valve *****" ARMSTRONG Niro Ventilator with conical female thread BSPT without lateral connection materials: - Housing and cover: stainless steel 304L - Valve & seat: Stainless steel 404 - Lever system: stainless steel 303/304 - Float: 304 stainless steel Max. perm. differential pressure = ***** bar PMO: 39 bar @ 38 ° C / 34 bar @ 360 ° C
13-AV-R 1 "valve 1 / 8th" ARMSTRONG Niro Ventilator with conical female thread BSPT without lateral connection materials: - Housing and cover: stainless steel 304L - Valve & seat: Stainless steel 404 - Lever system: stainless steel 303/304 - Float: 304 stainless steel Max. perm. differential pressure = 39 bar PMO: 39 bar @ 38 ° C / 34 bar @ 360 ° C Customs tariff number: 8481 8099 Country of origin: Belgium Weight: 3.4kg / pc
Armstrong
ARMSTRONG Inverted Bucket for horizontal installation with taper female thread NPT materials: - Housing: Stainless steel ASTM A240 304L - Internals: 304 stainless steel - Valve + seat: Stainless steel 17-4PH with cleaning wire Max. . Permissible differential pressure: 28 bar PMO: 28 bar @ 427 ° C
Inverted bucket KONDENSSTOP 16 BAR,max 350 C
(Valve-***** ARMSTRONG Inverted Bucket for horizontal installation with taper female thread NPT materials: - Housing: Stainless steel ASTM A240 304L - Internals: 304 stainless steel - Valve + seat: Stainless steel 17-4PH with cleaning wire Max. Perm. Differential pressure: ***** bar PMO: 28 bar @ 427 ° C Customs tariff number: 8481 8099 Country of origin: Belgium Weight: 1.0 kg / h)
Steam / water mixing station 3/4 "NPT inlets and outlets Station: brass / stainless steel Max. Vapor pressure: 10 bar minute Vapor Pressure: 1 bar incl. 15 m hot water hose incl. spray gun Weight: 33 kg
ARMSTRONG cast Traps with female thread (BSPT / NPT) for vertical installation Flow from bottom to top
ARMSTRONG cast Traps with female thread (BSPT / NPT) for vertical installation Flow from bottom to top
ARMSTRONG cast Traps with female thread (BSPT / NPT) for vertical installation Flow from bottom to top
ARMSTRONG cast Traps with female thread (BSPT / NPT) for vertical installation Flow from bottom to top
Mounting tool ½ ", extra long, 17 mm
ELECTRIC MOTORS,GEN, Precision Lathe Machine.Part# 660/3000 Brand:ARMSTRONG Specifications: Width of Bed:400mm Travel of Top Slide:190mm Swing Over Bed:6 60mm Swing In Gap:900mm Height of Center:1125mm Distance Between Centers:2000mm Spindle Speed:12 Steps Spindle Bore:86mm Spindle Dri ve Motor:10HP/4p Standard Acc: 1)3 Jaw Chuck 10"-1 Pc 2)Center Sleeve M.T No 6x4-1 Pc 3)Dead Center N.T.5 4)Leveling Screws-1 Set 5) Service Kits-1 Set 6)Main Motor 5HP(4P)-1 pC 7)Steady Rest-1 Pc 8)Drive Plate 9)Complete Coolant Equipment-1 Set
TORQUE WRENCH
2031E Steamix 3/4" BSPT
(DN50 / PN40 ARMSTRONG Float with thermostatic air vent and an integrated vacuum breaker for vertical installation Flow from top to bottom with cast flanges according to DIN / EN materials: - Housing: Ductile iron EN-GJS-400-15 (EN1563) - Internals: 304 stainless steel - Valve: Stainless steel 440 - Seat :: 303 stainless steel - Thermostatic Air Vent Hastelloy Capsule - Hexagon bolt: SAE Grade B2 Max. . Permissible differential pressure: 7 bar PMO: 17 bar @ 232 ° C D6365)
ARMSTRONG Inverted Bucket for horizontal installation with taper female thread NPT materials: - Housing: Stainless steel ASTM A240 304L - Internals: 304 stainless steel - valve seat +: titanium Max. . Permissible differential pressure: 45 bar PMO: 45 bar @ 315 ° C
811-F DN25 / PN40 valve 7/64 " ARMSTRONG Inverted Bucket for horizontal installation with screwed flanges according to DIN / EN Overall length: materials: - Housing: Cast Iron ASTM A48 30 - flanges: carbon steel - Internals: 304 stainless steel - Valve + seat: Stainless steel 17-4PH - Stopper: Steel Max. . Permissible differential pressure: 14 barPMO: 17 bar @ 232 ° C
814-F DN25 / PN40 valve-5/16 " ARMSTRONG Inverted Bucket for horizontal installation with screwed flanges according to DIN / EN Overall length: ... materials: - Housing: Cast Iron ASTM A48 30 - flanges: carbon steel - Internals: 304 stainless steel - Valve + seat: Stainless steel 17-4PH Max. . Permissible differential pressure: 8.5 barPMO: 17 bar @ 232 ° C
ARMSTRONG cast Traps with built-in strainer with female thread for horizontal installation
ARMSTRONG cast Traps with built-in strainer Einchraubflanschen with DIN for horizontal installation
ARMSTRONG cast Traps with built-in strainer Einschraubflanschen with DIN for horizontal installation
