| BRAND | JSP Industrial-Control |
| Product | T1070 06 F2 J23 L160 H4 S1 N145 P3 |
| Description | Resistance temperature sensor with thermowell |
| Internal code | ONR4914443 |
| Custom code | 90259000 |
| Technical specification | T1070 … Resistance temperature sensor with thermowell 06 … Temperature sensor 1× Pt100 / 4-wire, sheath material 1.4404 F2 … Accuracy class B according to EN 60751, measuring range -70 to 500 °C J23 … Fitting of the sensor with thermowell Ø 9×1 mm, extension Ø 14×2,5 mm, PN63, material 1.4541 L160 … Nominal immersion of sensor L = 160 mm H4 … Head Al alloy, with high cap for mounting of transmitter Ø 62 mm, cable outlet M20x1.5 for cable Ø 4 to 12.5 mm, IP 65 S1 … Cold-end of measuring insert with ceramic terminal block Ø 42 mm attached on flange of measuring insert N145 … Extension piece N = 145 mm P3 … Process connection male thread M20×1,5 + P5310 H11 QR P5310 … Low-cost programmable transmitter with LHP communication without galvanic isolation (accuracy 0,1 %) H11 … Version: into head B according to DIN, only for resistance sensors QR … setting of transmitter according to the order |
Discover the superior quality and performance of the JSP Industrial-Control T1070 06 F2 J23 L160 H4 S1 N145 P3 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The T1070 06 F2 J23 L160 H4 S1 N145 P3 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of T1070 06 F2 J23 L160 H4 S1 N145 P3 :
At Onrion LLC , we offer the T1070 06 F2 J23 L160 H4 S1 N145 P3 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the T1070 06 F2 J23 L160 H4 S1 N145 P3 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply JSP Industrial-Control products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
