BRAND | Planetroll |
Product | 0,047D2MRVP11-7,667-0(11k6x23) |
Description | planetroll control reducer |
Internal code | ONR4733447 |
Custom code | 8501 51 00 |
Technical specification | a) Three-phase motor b) Variable speed transmission “p l a r o m a s t e r” c) Planetary gears Dimension sheet: M070 802 specifications ------------------------- Installation side: right Design: B14-like Installation position: 4 Speed range: 0 to approx. 145/174 1/min (50/60 Hz) Output torques: approx. 4.5 Nm from 7.8/9.4 to 26 1/min approx. 1.5/1.2 Nm at 145/174 rpm 1 501-01220 1 PC three-phase motor 0.044/0.046 kW, 2600/3100 rpm, 230/400 V, 50/60 Hz, 0.27/0.16 A, IP 40, Isol.Kl.E, flange B14-62, centering collar diameter 26, shaft 9 x 25 mm 2 302-00008 1 PC plaromaster type MRV variable speed gearbox On the drive side: hollow drive shaft Ø9 with clamping element; centering Ø25, 4x Ø4.5 on TK36 On the output side: for mounting on type P11 planetary gears 3 302-00002 1 PC Control element type: HVN, coarse scale 0-12, fine scale 0-100 4 301-00962 1 PC On the output side, planetary gearbox type P11-0, reduction i = 7.667, 4x Bo.M4 to TC diameter 47, Output shaft dia.11k6 x 23, (max.allowable output torque M2=4.5 Nm). |
Discover the superior quality and performance of the Planetroll 0,047D2MRVP11-7,667-0(11k6x23) with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 0,047D2MRVP11-7,667-0(11k6x23) is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 0,047D2MRVP11-7,667-0(11k6x23) :
At Onrion LLC , we offer the 0,047D2MRVP11-7,667-0(11k6x23) at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the 0,047D2MRVP11-7,667-0(11k6x23) ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Planetroll products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
