BRAND | Kobold |
Product | UMC4-B11A00H |
Description | FLOWMETER |
Internal code | ONR4737363 |
Technical specification | TMU-S025-317B-A00-A0-10/UMC4-B11A00H 50000001 Coriolis mass flowmeter Model code sensor: TMU-S025-317B-A00-A0-10-0-H Model code measurement converter: UMC4-B11A00H Process data: Display range [kg/h]: 3000 Medium name: Molasses Density [kg/m3]: 1350 Viscosity [mPas]: 1 Process temperature [°C]: 60 (max 150) Process pressure [pe bar]: 4 Flow direction: left-right Sensor data: Parts in contact with the medium: 1.4571 (316Ti) /1.4404 (316L) Standard measurement range: min. 0 - 3,000 kg/h max. 0-30,000 kg/h Process connection: DN40 PN40 Form B1 DIN/EN1092 Pressure resistance: 40 bar Sensor housing: stainless steel housing 1.4301 (304) Housing pressure resistance: 0 bar Sensor protection class: IP66 (EN60529) Heating/cooling: none Heating/cooling connection: without Measurement converter arrangement: built-in measurement converter Temperature range: -20 to 100°C Sensor connection: - Approval: none Mass flow calibration: standard, 3-point Calibration density: none Overall length: 600 mm PED: CAT II Type: UMC4 Mounting type: built-in measurement converter Sensor connection: - Cable screw thread: M20x1.5 Display and control unit: built-in control unit Display language: English Supply voltage: 90-265V AC; 50/60 Hz Current output 1 (passive): 0/4-20 mA with HART® protocol mass flow rate, temperature volume flow rate, density Current output 2 (passive): 0/4-20 mA mass flow rate, temperature volume flow rate, density Pulse output 1:.. Imp/kg passive Status output 2: passive Forward/backward measurement alarm MIN/MAX flow MIN/MAX density MIN/MAX temperature Approval: none Ignition protection type signal outputs: without Ambient temperature: -20 to +60°C Protection class measurement converter: IP66 (EN60529) Characteristics: Measurement uncertainty (measurement range): ± 0.1% of the measured value plus zero point stability Repeatability: ± 0.05% of measured value ± 1/2 zero point stability Pressure loss: ~ 0.02 bar at 3000 kg/h |
Discover the superior quality and performance of the Kobold UMC4-B11A00H with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The UMC4-B11A00H is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of UMC4-B11A00H :
At Onrion LLC , we offer the UMC4-B11A00H at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the UMC4-B11A00H ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Kobold products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
