BRAND | Johnson Controls |
Product | VA7830-GGA-11 |
Internal code | ONR4961781 |
Technical specification | specifications Operating voltage: 24 V AC, 50/60 Hz power consumption: 11 VA Effective power: 8 W at 3 s/mm, 6 W at 6 s/mm Input impedance: 0 (2)... 10 V: min. 100 kΩ /0 (4)... 20 mA: min. 120 Ω Control: continuous: 0 (2)... 10 V DC or 0 (4)... 20 mA Feedback: 2 mA max at 0 (2) V DC to 10 V DC, input impedance min 5 kΩ Positioning force: 1000 N +30/-20% max. stroke: 8 to 25 mm Runtime: selectable: 6 s/mm ± 10% or 3 s/mm ± 10% Behavior in case of power failure: spindle moves out Spring return time in case of power failure: 1.4 s/mm Operating conditions: ‐5 °C to +55 °C, 10 to 90% RH condensing material Gearbox, bracket: Die-cast aluminum Housing: resin ABS/PC, self-extinguishing according to UL94 V-0 Spindle: stainless steel Coupling: brass |
Discover the superior quality and performance of the Johnson Controls VA7830-GGA-11 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The VA7830-GGA-11 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of VA7830-GGA-11 :
At Onrion LLC , we offer the VA7830-GGA-11 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the VA7830-GGA-11 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Johnson Controls products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
