BRAND | Valco |
Product | VM-020.GR.040T.IP65/0213.WPS |
Description | Flow switch |
Internal code | ONR4041712 |
Technical specification | Compensated 1..200 Cst Type VM-020.GR.040T.IP65/0213.WPS Body material: bronze Process connections 3/4" Gas-F Piston sensing element Maximum working pressure bar Max working temperature 90°C Setting range 10 -40 l/min H2O Adjustable by means of the calibration graph on board of the instrument Wide calibration scale, graduated: 0..170° mechanical degrees Maximum recommended flow 40 l/min H2O Pressure drop at maximum recommended flow 0.25 bar Microswitch SPDT Maximum electrical load: Electrical output: Plug DIN-43650-A - PG9 cable gland Protection class IP65 Code 00.0001.0532 |
Discover the superior quality and performance of the Valco VM-020.GR.040T.IP65/0213.WPS with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The VM-020.GR.040T.IP65/0213.WPS is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of VM-020.GR.040T.IP65/0213.WPS :
At Onrion LLC , we offer the VM-020.GR.040T.IP65/0213.WPS at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the VM-020.GR.040T.IP65/0213.WPS ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Valco products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
