| BRAND | Ascon |
| Product | XP 3100 |
| Description | XP Series Digital Controller (3 point step, unconfigured) G.No.: |
| Internal code | ONR487608 |
| Weight | 1 |
| Technical specification | G.No. A.No.: - Supply voltage: 100... 240V, 50/60 Hz - serial interface: ASCII protocol - Auxiliary output Y4: without - Setpoint: Fixed value controller 1 internal setpoint and 4 stored or 1 external setpoint (4... 20 mA or 0... 10 V) - Control output Y1:2 relays (motor on/motor closed) - Auxiliary output Y2: Alarm relay (configurable as deviation, band, limit value or loop Breakalarm) - Auxiliary output Y3: Alarm relay (configurable as deviation, band, limit value or loop Breakalarm) - Control characteristics: 3-way step (servo control) - Ma km: 96*48 mm (DIN), depth 150 mm - Degree of protection: Front IP54 |
Discover the superior quality and performance of the Ascon XP 3100 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The XP 3100 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of XP 3100 :
At Onrion LLC , we offer the XP 3100 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the XP 3100 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Ascon products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Temperature Controller
Temperature controller series M3 (unconfigured)
M3-5107-0200/9999 (M3-5107-0200)
Temperaturregler Serie M3 (unkonfig)
Transmitterversorgung und Analog-Ausgang
temperature controller
thermostat
(Controller / program controller series M5-3100-1200 A-No .: G-No .: Front: 48 x 48 mm Supply voltage: 100 ... 240 V, 50/60 Hz Logic inputs: 2 Auxiliary input: no Output OP1: relay (2A / 250V contact) Output OP2: relay (2A / 250V contact) Output OP3: relay (2A / 250V contact) Serial interface: no Interface protocol: no Actual value OP4: no Front color: dark gray Setpoint program: up to 16 segments can be configured as follows: Input: PT100; Thermocouple J, L, T, K, S, R, T; 0 ... 50 mV DC 0 (1) .... 5 V DC; 0 .... 10V DC, 0 (4) ... 20 mA Control: ON / OFF, PID, heating or cooling, Heating / cooling, 3 pt step Options: ext. Setpoint, current transformer Entrance, continuous control output, or serial interface)
.Regler Series M5-3101-0200 (unkonfiguriert)
Policy
.regler
HEAT INDICATOR
M9-3151-0000 price valid only in 6-pack
user manual in English only (Gewicht 250g)
M9-3151-0000/AHL OEM/Kundenspezifisch
regulator Type: M9-3151-0000 / AHL Case dimensions: 48 x 48 mm Power supply: 100 ... 240V AC with 2 relay outputs Serial interface RS485 + IPOT
Policy
MS-30/30 ABA(replaced by MS-32/.9999)
Configuration 99/99 Power supply 100/240V
(Digital Controls MS (series unconfigured) - Power supply voltage: 100 ... 240V, 50/60 Hz - Serial interface: 2-wire TTY, ASCII optinoal - Dimensions: 48 x 48 mm DIN, depth 110 mm - Weight approx 200 g - input (configurable): * Pt100 * Thermocouple (L, J, K, S) * Standard signal 0 (4) ... 20 mA or 0 ... 1 (10) V Exit: * Main output Y1: relay or logic * Auxiliary output Y2: Alarm relay - PID control with self-optimization and setpoint ramp - heating or cooling characteristic with alarm output or Heating / cooling characteristic without alarm output configurable - Simultaneous display of set and actual values - control output configurable as relays or logic signal - ramp function - Power limitation - scalable inputs for standard signals - configuration via front keys - Voltage output for external 24 V - Transmitter - Parameter lock - Front protection: IP 54, with transparent cover IP 65 (optional) - Customs number: 9032/1020)
