BRAND | TEKNIC |
Product | CPM-SDSK-3441S-RLN |
Internal code | ONR3935190 |
Custom code | 8501100000 |
Technical specification | Motor Frame SizeNEMA 34 - 3.42 in (86.87 mm) sq. Length5.38 in (136.65 mm) Input (bus) Voltage Range24-75 VDC (90 VDC max) Peak Torque (@75 VDC)1,844 oz-in (13.0 N-m) Cont. (RMS) Torque (@75 VDC)479 oz-in (3.4 N-m) Max Speed (@75 VDC)840 RPM Achievable Resolution0.450 degrees (0.057 deg. w/ Enhanced option) Repeatability0.03 degrees Shaft Diameter0.50 in (12.70 mm) Weight7.3 lb (3.3 kg) Rotor Inertia15.5 oz-in² (2.8 kg-cm²) Logic Input Voltage Range4.0 to 28 VDC Maximum Radial Load50 lbf (222.4 N) Maximum Thrust Load10.0 lbf (44.5 N) Environmental RatingDust & water splash resistant Ambient Temperature0-70 deg C (derated >40C) Ambient Humidity0-95%; non-condensing Regulatory CertificationsUL recognized; cUL recognized; CE; RoHS Country of OriginUSA Warranty3 Years Specifications at 75 VDC Peak Torque 1,844 oz-in (13.0 N-m) Cont. (RMS) Torque 479 oz-in (3.4 N-m) Max Speed 840 RPM Peak Power 280 W (0.38 hp) Cont. (RMS) Power 251 W (0.34 hp |
Discover the superior quality and performance of the TEKNIC CPM-SDSK-3441S-RLN with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CPM-SDSK-3441S-RLN is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CPM-SDSK-3441S-RLN :
At Onrion LLC , we offer the CPM-SDSK-3441S-RLN at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the CPM-SDSK-3441S-RLN ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply TEKNIC products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
