BRAND | Stahl |
Product | p/n: 242341; Type: 8572/14-306 |
Description | coupling socket explosion-proof |
Internal code | ONR3868848 |
Custom code | 85366990 |
Technical specification | Rated operating voltage AC: 250 V Frequency range: 50 - 60 Hz Detailed number of pins: 2 P + PE Identification colour: blue Encoding (time setting): 6 Auxiliary contacts available: No Case Material: Polyamide Area of application (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex db eb IIC T6 Gb Dust Explosion Protection: II 2 D Ex tb IIIC T75 °C Db Ambient temperature min. ፦50 °C Ambient temperature max.: +45 °C Rated operating current: 16 A Ambient temperature max. 2: +55 °C Rated operating current2:12 A Ambient temperature max. 3: +65 °C Rated operation current3:10 A Degree of protection (IP): IP66 Introductions፦ Cable and Cable Entrances፦ Cable diameter: 8... 15 mm Sealing Plugs፦ |
Discover the superior quality and performance of the Stahl p/n: 242341; Type: 8572/14-306 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The p/n: 242341; Type: 8572/14-306 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of p/n: 242341; Type: 8572/14-306 :
At Onrion LLC , we offer the p/n: 242341; Type: 8572/14-306 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the p/n: 242341; Type: 8572/14-306 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Stahl products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
