BRAND | Jokwang |
Product | spare parts for JSV-FF100 |
Internal code | ONR4506514 |
Technical specification | • Item 01 - ALIV/SAFE VALVE 40.00MM 80.00MM 38MPA RELIEF/SAFETY VALVE; INLET DIAMETER: 40.00MM; OUTLET DIAMETER: 80.00MM; HOLE SECTION: 506.45MM2; CONSTRUCTION STANDARD: ANSI 150; BODY MATERIAL: CARBON STEEL 216WCB; CASTLE MATERIAL: CARBON STEEL A216WCB; SHUTTER MATERIAL: ASTM A276 316 STAINLESS STEEL; SPRING MATERIAL:SWOSC; HOOD MATERIAL: CARBON STEEL A216WCB; SEALING MATERIAL: POLYTETRAFLUORETHYLENE; PRESSURE CLASS: 1500LBS; OUTLET PRESSURE: 30MPA; MAXIMUM OPENING PRESSURE: 38MPA; OPERATING TEMPERATURE: 40GRC; END: FLANGE; ACTIVATION: SPRING; COMPRESSED AIR; 1793KG/H; Quantity - 2 Units. • Item 02 - ALIV/SAFE VALVE 4POL 6POL 20BAR RELIEF/SAFETY VALVE; INLET DIAMETER: 4IN; OUTLET DIAMETER: 6IN; HOLE SECTION: 4115.48MM2; BODY MATERIAL: CARBON STEEL A216 WCB; CASTLE MATERIAL: CARBON STEEL A216 WCB; SHUTTER MATERIAL: SA276 316STELLITE; SPRING MATERIAL: SAE9254; HOOD MATERIAL: CARBON STEEL A216WCB; SEALING MATERIAL: SA276 316 STELLITE; PRESSURE CLASS: 300 LBS/POL2; OUTLET PRESSURE: 23BAR; MAXIMUM OPENING PRESSURE: 20BAR; OPERATING TEMPERATURE: 40A260GRC; END: FLANGE; ACTIVATION: LEVER; STEAM; 47221KG/H; Quantity - 1 Unit. • Item 03 - ALIV VALVE 1.1/2POL 3POL 10BAR RELIEF VALVE; INLET DIAMETER: 1.1/2IN; OUTLET DIAMETER: 3POL; HOLE SECTION: 326.45MM2; FLUID: AIR; FLOW: 2866KG/H; BODY MATERIAL: ACOCARBON A216WCB; SHUTTER MATERIAL: SA276 316 STELLITE; SPRING MATERIAL: STEEL SPRING JIS G 3560; HOOD MATERIAL: CARBON STEEL A216WCB; SEALING MATERIAL: POLYTETRAFLUORETHYLENE; PRESSURE ADJUSTMENT: 10BAR; MAXIMUM OPENING PRESSURE: 10BAR; END: FLANGE; LEVER: WITHOUT LEVER; ISO 4126; Quantity - 1 Unit. • Item 04 - ALIV VALVE 1.1/2POL 3POL 9BAR RELIEF VALVE; INLET DIAMETER: 1.1/2IN; OUTLET DIAMETER: 3POL; FLUID: NITROGEN; FLOW: 2866KG/H; BODY MATERIAL: CARBON STEEL A216WCB; SHUTTER MATERIAL: SA276 316 STELLITE; SPRING MATERIAL: JIS G 3560 SPRING STEEL; HOOD MATERIAL: CARBON STEEL A216WCB; SEALING MATERIAL: POLYTETRAFLUORETHYLENE; PRESSURE ADJUSTMENT: 10BAR; MAXIMUM OPENING PRESSURE: 9BAR; END: FLANGE; LEVER: WITHOUT LEVER; ISO 4126; Quantity - 1 Unit. • Item 05 - ALIV VALVE 3POL 4POL 7.7BAR RELIEF VALVE; INLET DIAMETER: 3POL; OUTLET DIAMETER: 4POL; ORIFICE SECTION: 1,187.74MM2; FLUID: NITROGEN; FLOW: 9315KG/H; MATERIALBODY: CARBON STEEL A216WCB; SHUTTER MATERIAL: SA276 316 STELLITE; SPRING MATERIAL: SPRING STEEL SUP9; HOOD MATERIAL: CARBON STEEL A216WCB; SEALING MATERIAL: POLYTETRAFLUORETHYLENE; PRESSURE ADJUSTMENT: 9BAR; MAXIMUM OPENING PRESSURE: 7.7BAR; END: FLANGE; LEVER: WITH LEVER; ISO 4126; Quantity - 2 Units. • Item 06 - ALIV VALVE 1POL 2POL 32.4BAR RELIEF VALVE; INLET DIAMETER: 1IN; OUTLET DIAMETER: 2IN; HOLE SECTION: 12.7MM2; FLUID: NITROGEN; FLOW: 3694KG/H; BODY MATERIAL: CARBON STEEL A216WCB; SHUTTER MATERIAL: SA276 316 STELLITE; SPRING MATERIAL: JIS G 3560 SPRING STEEL; HOOD MATERIAL: CARBON STEEL A216WCB; SEALING MATERIAL: POLYTETRAFLUORETHYLENE; ADJUSTING PRESSURE: 36BAR; MAXIMUM OPENING PRESSURE: 32.4BAR; END: FLANGE; LEVER: WITHOUT LEVER; ISO4126; Quantity - 1 Unit. • Item 07 - VALVE SEG 7A10BAR 3POL 4POL SAFETY VALVE PRESSURE CLASS: 150LBS; MAXIMUM OPENING PRESSURE: 9BAR; WORKING PRESSURE: 7A10BAR; FLOW: 10427KG/H; BODY MATERIAL: CARBON STEEL A216WCB; SPRING MATERIAL: SPRING STEEL; SEAT SEALING MATERIAL: RETHYLENE POLYTETRAFLUO; END: FLANGE; INLET DIAMETER: 3POL; OUTLET DIAMETER: 4POL JSV-FF100 JOKWANG Quantity - 1 Unit. • Item 08 - VALVE SEG 7BAR 1.1/2POL 2POL SAFETY VALVE; PRESSURE CLASS: 150LBS; MAXIMUM OPENING PRESSURE: 10BAR; WORKING PRESSURE: 7BAR; FLOW: 1744KG/H; BODY MATERIAL: CARBON STEEL A216WCB; SPRING MATERIAL: SPRING STEEL; SEAT SEALING MATERIAL: POLYTETRAFLUORETHYLENE; END:FLANGE; INLET DIAMETER: 1.1/2IN; OUTLET DIAMETER: 2IN; JSV-FF100 JOKWANG Quantity - 2 Units. • Item 09 - VALVE SEG 300LBS 1.1/2POL 3POL SAFETY VALVE PRESSURE CLASS: 300LBS MAXIMUM OPENING PRESSURE: 30BAR WORKING PRESSURE: 25BAR FLOW: 7529KG/H BODY MATERIAL: CARBON STEEL A216WCB SPRING MATERIAL: STEEL SPRING SEAT SEALING MATERIAL: POLYTETRAFLUORETHYLENE END: FLANGE INPUT DIAMETER: 1.1/2POL OUTPUT DIAMETER: 3POL JSV-FF100 JOKWANG Quantity - 4 Units. • Item 10 - VALVE SEG 16A25BAR 1POL 2POL SAFETY VALVE PRESSURE CLASS: 300LBS 150LBS; WORKING PRESSURE: 16A25BAR; FLOW: 2593KG/H; BODY MATERIAL: CARBON STEEL A216WCB; SPRING MATERIAL: SPRING STEEL; END: FLANGE; INLET DIAMETER: 1IN; OUTLET DIAMETER: 2IN MODEL JSV-FF100 JOKWANG Quantity - 2 Units. |
Discover the superior quality and performance of the Jokwang spare parts for JSV-FF100 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The spare parts for JSV-FF100 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of spare parts for JSV-FF100 :
At Onrion LLC , we offer the spare parts for JSV-FF100 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the spare parts for JSV-FF100 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Jokwang products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
