BRAND | Reitz |
Product | spare parts for KXE 035-037515-00 |
Description | Fan spare parts |
Internal code | ONR4662994 |
Technical specification | Fan type: KXE 035-037515-00 Chassis position: GL90 Fan list: L12/2002 Commission: Koncal 1 x DRD000-000000-00 Twist controller D2, overall length: 250 mm, with adjustment ring and preparation for servomotor, DN 560 from 1.0038 according to DIN 24154 R2, temperature-resistant up to 180°C Outer surface treatment: hand rust removal Internal surface treatment: hand rust removal Primer: Derogrund Hydro XT, RAL 7040, 80μ Top coat: 2K Derocryl 80 HS, RAL 5017, 250μ 1 x SMB530-111105-00 Pneumatic rotary actuator, brand BAR, type: GS-105/090-B-8-F07/F10-V22, single-acting with spring return, pneumatic net torque at 4 bar 53 Nm, ambient temp. -50°C... 70°C 1 x SMB530-000001-00 Additional option for Pneum. Rotary drive, 3/2-way NAMUR control valve, 24V DC voltage. Rotary drive closed without current including SDR throttling muffler 1 x SMB530-000009-00 Option module for Sipart PS2 positioner, position feedback type 6DR4004-8J, output 4 to 20 mA, ambient temp. -30... 80°C |
Discover the superior quality and performance of the Reitz spare parts for KXE 035-037515-00 with Onrion LLC in United States . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The spare parts for KXE 035-037515-00 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of spare parts for KXE 035-037515-00 :
At Onrion LLC , we offer the spare parts for KXE 035-037515-00 at competitive prices and with the fastest delivery times across United States . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Onrion LLC ?
Get Your Quote Today! Ready to enhance your operations with the spare parts for KXE 035-037515-00 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Reitz products, Onrion LLC is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
